Description
Key Features
Main milling & drilling unit: 4 tools
Turning unit: 2 tools
Control system: LNC (Taiwan)
Heavy-duty turning axis servo system: 4 kW
Handwheel remote control for easy machine calibration
Automatic feeding system
1/ Main Milling & Drilling Unit
Spindle motor power: 5.5 kW × 2
Spindle speed: 12,000 rpm
Spindle collet: ER25 + ER32
Number of tools: 4 types of tools
2/ Turning Unit
2 independent turning tools
Dual left-right positioning for flexible tool use
3/ Sanding Unit
Motor power: 1.5 kW
Sanding belt speed: 2860 rpm
Technical Specifications
Working length: 200 – 1200 mm
Maximum working diameter: 270 mm
Required air pressure: 6 – 7 kg/cm2
Machine dimensions: 3300 × 2420 mm
Machine weight: 2500 kg
Main milling & drilling unit: 4 tools
Turning unit: 2 tools
Control system: LNC (Taiwan)
Heavy-duty turning axis servo system: 4 kW
Handwheel remote control for easy machine calibration
Automatic feeding system
1/ Main Milling & Drilling Unit
Spindle motor power: 5.5 kW × 2
Spindle speed: 12,000 rpm
Spindle collet: ER25 + ER32
Number of tools: 4 types of tools
2/ Turning Unit
2 independent turning tools
Dual left-right positioning for flexible tool use
3/ Sanding Unit
Motor power: 1.5 kW
Sanding belt speed: 2860 rpm
Technical Specifications
Working length: 200 – 1200 mm
Maximum working diameter: 270 mm
Required air pressure: 6 – 7 kg/cm2
Machine dimensions: 3300 × 2420 mm
Machine weight: 2500 kg
