Description
Model: YQCP500T.
Total pressure: 500 tons.
Board feeding direction: Transverse.
Opening: 1600mm.
Working size: 2700*1370mm.
Cylinder diameter: 2*o360mm.
Cylinder stroke: 1000mm.
Cylinder model: Wuxi cylinder, solid steel.
Cylinder seal: 5 rubber seals per cylinder.
Compression resistance: 25 Mpa.
High pressure pump flowing: 25ml/r*1pcs.
Power: 7.5KW.
Composite frame: Assembled.
Upper and bottom beam: 900mm.
Middle beam: 400mm.
Main body: 30mm Q235.
Conveyor: Roller and spring infeed and outfeed with chain.
Overall dimension: 3550mm*1400mm*4600mm.
Weight: About 12Tons.
Total pressure: 500 tons.
Board feeding direction: Transverse.
Opening: 1600mm.
Working size: 2700*1370mm.
Cylinder diameter: 2*o360mm.
Cylinder stroke: 1000mm.
Cylinder model: Wuxi cylinder, solid steel.
Cylinder seal: 5 rubber seals per cylinder.
Compression resistance: 25 Mpa.
High pressure pump flowing: 25ml/r*1pcs.
Power: 7.5KW.
Composite frame: Assembled.
Upper and bottom beam: 900mm.
Middle beam: 400mm.
Main body: 30mm Q235.
Conveyor: Roller and spring infeed and outfeed with chain.
Overall dimension: 3550mm*1400mm*4600mm.
Weight: About 12Tons.
